7B9-PK 90° 弯头英制锥螺纹内螺纹 ISO 1179
| 软管内径 | 尺寸 | ||||||
| 部件号. | 主题 M | DN | DASH | 管外径. | C | S | L |
| 10411-12-04 | M12×1.5 | 6 | 04 | 6 | 10 | 12 | 20.5 |
| 10411-14-04 | M14×1.5 | 6 | 04 | 8 | 10 | 14 | 20.5 |
| 10411-14-05 | M14X1.5 | 8 | 05 | 8 | 10 | 14 | 21.5 |
| 10411-16-04 | M16×1.5 | 6 | 04 | 10 | 11 | 17 | 22.5 |
| 10411-16-05 | M16×1.5 | 8 | 05 | 10 | 11 | 17 | 22.5 |
| 10411-18-05 | M18×1.5 | 8 | 05 | 12 | 11 | 19 | 23.5 |
| 10411-18-06 | M18×1.5 | 10 | 06 | 12 | 11 | 19 | 23.5 |
| 10411-22-06 | M22×1.5 | 10 | 06 | 15 | 12 | 24 | 24.5 |
| 10411-22-08 | M22×1.5 | 13 | 08 | 15 | 12 | 24 | 26 |
| 10411-26-08 | M26×1.5 | 13 | 08 | 18 | 12 | 27 | 26.5 |
| 10411-26-10 | M26×1.5 | 16 | 10 | 18 | 12 | 27 | 27 |
| 10411-30-10 | M30×2.0 | 16 | 10 | 22 | 14 | 32 | 29 |
| 10411-30-12 | M30×2.0 | 19 | 12 | 22 | 14 | 32 | 29 |
| 10411-36-12 | M36×2.0 | 19 | 12 | 28 | 14 | 38 | 30.5 |
| 10411-36-16 | M36×2.0 | 25 | 16 | 28 | 14 | 41 | 31.5 |
| 10411-45-20 | M45×2.0 | 32 | 20 | 35 | 16 | 46 | 36 |
| 10411-52-24 | M52×2.0 | 38 | 24 | 42 | 16 | 55 | 38 |
| 注：1.适用于编织软管。 2.如与螺旋软管一起使用，软管接头系列号为 10412-XX-XX。. | |||||||
